產品說明

規 格

No.

扭力 T

kg.m

A

B

C

D

E

F

G

H

I

J

K

L

M

N

Q

孔徑範圍

V

T

X

(Z)

PDF

圖檔

DWG

圖檔

3D

圖檔

S

U

ST4C-007C

0.03-0.07

64

52

PCD
40

34H7

32

M20
P1

5

28

27

20.5

R+5

7.6

4.M5

P0.8

4-M4

P0.7

深4.7

7

15

4.5

27

0.7

0.6

ST4C-010C

0.04-0.10

8.0

1.1

0.2

ST4C-030C

0.1-0.30

7.6

0.7

0.6

ST4C-045C

0.15-0.45

8.0

1.1

0.2

ST5C-030C

0.08-0.30

82

71

PCD
55

46H7

45

M30
P1.5

7

40

39

30

R+7

13.1

4.M6
P1

4-M4

P0.7

深5.7

8

22

5.5

36

0.6

0.3

ST5C-060C

0.15-0.60

13.7

1.2

-0.3

ST5C-100C

0.20-1.00

13.1

0.6

0.3

ST5C-180C

0.40-1.80

13.7

1.2

-0.3

ST6C-06C

0.2-0.6

93

95

PCD
70

50H7

58

M40
P1.5

9

52

40

R+8

18.5

2.M5

P0.8

8-M6

P1

深9

15

27

1.4

3.2

ST6C-1C

0.3-1.0

19.0

2.2

2.8

ST6C-3C

1.0-3.0

18.5

1.4

3.2

ST6C-5C

1.5-5.0

19.0

2.2

2.8

ST7C-6A

2-6

128

116

PCD
90

70H7

88

55

10

65

52

R+9

30.0

2.M5

P0.8

8-M8

P1.25

深10

102

20

35

1.6

2.0

ST7C-10A

3-10

31.0

2.6

0.9

ST7C-20B

6-20

30.0

1.6

1.7

ST7C-35B

10-35

31.0

2.6

0.6

ST8C-12A

4-12

164

142

PCD
110

90H7

108

75

12

75

60

R+11

35.0

2.M5
P0.8

8-M8
P1.25
深12

130

20

51

1.7

2.5

ST8C-15A

6-12

36.0

2.7

1.6

ST8C-35B

10-35

35.0

1.7

1.8

ST8C-45B

12-45

36.0

2.7

0.9

ST11C-20A

7-20

198

176

PCD
130

110H7

134

96

16

90

70

R+15

41.5

2.M5

P0.8

8-M10

P1.5

深16

160

28

65

2.0

2.4

ST11C-35A

10-35

43.0

3.2

1.0

ST11C-65B

20-65

41.5

2.0

0

ST11C-100B

30-100

43.0

3.2

-1.5

ST14C-30A

10-30

236

208

PCD
160

130H7

158

120

16

100

80

R+15

44.0

2.M5

P0.8

8-M12

P1.75

深16

186

30

90

2.7

4.5

ST14C-45A

15-45

44.0

4.3

4.5

ST14C-130B

50-130

44.0

2.7

3.5

ST14C-200B

80-200

44.0

4.3

3.5

ST18C-160A

70-160

285

285

PCD
220

170H7

220

170

18

130

108

R+17

59.0

2.M5

P0.8

8-M16

P2

深18

236

50

130

3.7

4.8

ST18C-250A

100-250

59.0

6.2

5.0

ST18C-380B

160-380

59.0

3.7

5.0

ST18C-500B

300-500

59.0

6.2

5.2

規 格

No.

Tmax

kg.m

Ymax

mm

P

mm

θ

deg

α

mm

β

mm

Nmax

rpm

GD²

kgf.m²

W

(kg)

ST4C-007C

0.07

4.0

1

1

±1.0

0.05

2000

3.6 x 10^-4

0.25

ST4C-010C

0.10

2.7

ST4C-030C

0.30

4.0

ST4C-045C

0.45

3.3

ST5C-030C

0.30

4.2

1.5

1

±1.0

0.05

1600

1.6 x 10^-4

0.68

ST5C-060C

0.60

5.9

ST5C-100C

1.00

6.8

ST5C-180C

1.80

7.5

ST6C-06C

0.6

11.0

1.5

1.5

±1.5

0.05

1000

6.7 x 10^-3

1.5

ST6C-1C

1

11.0

ST6C-3C

3

11.0

ST6C-5C

5

11.0

ST7C-6A

6

9.0

2

1.2

±1.8

0.1

700

2.3 x 10^-2

3.2

ST7C-10A

10

8.0

ST7C-20B

20

9.0

ST7C-35B

35

7.5

ST8C-12A

12

11.0

2

1.2

±2

0.1

500

5.5 x 10^-2

5.3

ST8C-15A

15

10.0

ST8C-35B

35

10.5

ST8C-45B

45

9.5

ST11C-20A

20

13.5

2

1

±2.5

0.1

400

0.14

10.8

ST11C-35A

35

12.0

ST11C-65B

85

9.0

ST11C-100B

100

7.5

ST14C-30A

30

12.0

2

0.7

±3.5

0.1

300

0.37

20

ST14C-45A

45

12.0

ST14C-130B

130

13.5

ST14C-200B

200

13.5

ST18C-160A

160

16.0

3

0.5

±3.5

0.1

200

1.6

45

ST18C-250A

250

16.0

ST18C-380B

380

15.0

ST18C-500B

500

15.0
